RAMCRO

Ramcro fire resistant cable range is designed to ensure that emergency systems in public buildings continue to operate in some of the most extreme fire conditions.

Fire Resistant Cables for Fire Alarm Systems, Emergency Lighting & Voice Evacuation Systems, often also referred to as fire survival cables, fire-proof cables, fire alarm cables, or simply fire.

LPCB Certified

BASEC Certified

ESMA Certified

Approved by Civil Defense of Dubai, Sharjah & Abu Dhabi

Approved by Bahrain Civil Defense

Approved by Royal Oman Police (ROP)

RAMCRO cables are used for Fire Resistant & Circuit Integrity and essential to prevent life from smoke and noxious fumes, and where sensitive equipment may be damaged by acid forming gases.

Ramcro Fire resistant cables are with sub –branded Ramfirecro, are manufactured to meet the requirements in accordance with the major international standards. ie, BS 7629/BS 6387, CWZ/IEC 60331-21/ EN50200 PH120/BS 8434-2/ etc.

Ramcro Fire Resistant Cable Range

Fire Planet – BS 6387 CWZ, Multi-core, Solid/Stranded CU, Silicon Rubber – Insulation, Collective screen, LSZH – Sheath

Fire Sun – BS 7629, Multi-core, Solid/Stranded CU, Silicon Rubber – Insulation, Collective screen, LSZH – Sheath

Fire Star – Enhanced BS 8434-2 Multi-core Solid/Stranded CU, Mica+ XLPE + Silicon Rubber – Insulation, Collective screen, LSZH – Sheath

Multi-Core, Plain annealed copper wire Solid/ Stranded, Special Mix Silicon Rubber-Insulation, Collective Screen Aluminium / PETP tape over copper drain wire, LSZH Sheath.

• Sheath Colour:Red or White

• BS 6387:2013 Cat. C-W-Z

• EN 60754-1:2014

• EN 61034-2:2005

• EN 50200:2015 (Class PH120)

• EN 50200:2015 Annex E (30 mins)

• EN 60754-2:2014

Multi-Core, Plain annealed copper wire Solid/ Stranded, Special Mix Silicon Rubber-Insulation, Collective Screen Aluminium / PETP tape over tinned copper drain wire, LSZH Sheath.

• Sheath Colour: Red or White

• BS 7629-1:2015 (Standard 60)

• BS 6387:2013 (CWZ)

• EN 50200:2015 (Class PH120)

• EN 50200:2015 Annex E (30 mins)

• BS 5839-1:2013 (Clause 26.2d Standard)

• EN 60754-2:2014

Multi-Core, Plain annealed copper wire Solid/ Stranded, MICA+XLPE / Special Mix Silicon Rubber-Insulation, Collective Screen Aluminium / PETP tape over tinned copper CC Core, LSZH Sheath.

• Sheath Colour: Red or White
• BS 7629-1:2015 Enhanced 120
• EN 50200:2015 (Class PH120)
• BS 8434-2:2003+A2:2009 (120 mins)
• BS 5839-1:2013 (Clause 26.2e Enhanced)
• BS 6387:2013 Category CWZ

Control & Building Management System (BMS) Cables are special extra low voltage cables for data transmission and communication. These cables are specially constructed cables for ELV systems which carries low voltage signals with accuracy and protection from any external disturbances or influences coming in the form of electromagnetic vibrations from neighbouring cables or devices. BMS Cables transmit data related to the monitoring and control of various building systems such as HVAC, lighting, and security etc.

The cable is compatible with various communication protocols such as LON, BACnet, Modbus, M-bus, EIB, Profibus, KNX or General Bus and Field bus, making it versatile and adaptable to different systems.

Ramcro Control & BMS Cables Range

• Multi Conductor Cable

• Paired Cable

• Data cable

• KNX Cable

• Speaker Cable

Available in

• PVC Jacket

• LSZH / LS0H Jacket – Low Smoke Zero Halogen

Applications:

• Building Management System, Home Automation, Lighting Control, Access Control, Security, Guest Room Management System (GRMS), Public Address System.

• Configuration: Multi-conductor cables with minimum 2 cores, up to 8 cores or more

• Application: Used for field devices and signal transmission

• Design: Specially constructed for both signal and power transmission

• Usage: Suitable for controllers, meters, and data gathering devices

• Application: Mainly used for communication systems

• Construction: Twisted pair configuration

• Conductor: Tinned copper

• Benefit: Tinning protects copper and increases lifespan against environmental/seasonal damage

• Type: KNX cable (paired cable)

• Conductor: Solid copper conductors

• Construction: Twisted pair configuration (typically 2 pairs / 4 cores)

• Application: Used for lighting control, building automation, and communication systems

• System Use: Suitable for KNX / EIB building management systems

Instrumentation Cable

These cables are designed to connect electrical instrument circuits and provide communication services in and around process plant (e.g. petrochemical industry etc.). Inside a complete gamma suitable for few applications and critic installations.

Instrumentation cables designed to carry communication and control signals in a variety of installation types including those found in the petrochemical industry. The signals can be of analogue, data or voice type and from a variety of transducers such as pressure, proximity or microphone.
