SINGLE DOOR ENCLOSURE

• High quality electro-galvanized steel.
• Matt-finish polyester powder coating.
• Steel Thickness up to 1.5 mm.
• Removable gland plate at the bottom side.
• Corner formed door ensures better weatherproofing and gives aesthetic looks.
• Gasket on door ensures better sealing.
• Dimensions : From 200 x 200 mm To 2000 x 1000 mm
• Depths : From 150 mm To 400 mm
• Ingress protection : IP66

MODULAR ENCLOSURE

• Material: High quality electro-galvanized steel
• Number of rails: From 1 To 6
• Number of modules per rail: 12, 16 or 24.
• Metal thickness: 1.2 mm
• Door: Single door
• Ingress protection: IP41

DOUBLE DOOR ENCLOSURE

• High quality electro-galvanized steel.
• Matt-finish polyester powder coated.
• Steel Thickness up to 1.5 mm.
• Corner formed door ensures better weatherproofing and gives aesthetic looks.
• Gasket on door ensures better sealing.
• Available dimensions:
• 1000 x 1000 mm. to 2000 x 1200 mm.
• Depths: From 300 mm To 400 mm
• Ingress protection : IP54

METERING ENCLOSURE

• Made of EG steel of 1.5 mm thickness, polyester powder coated.
• Mounting plate made of GI steel sheet (2 mm thickness), powder coated.
• Meter viewing Perspex 150X150 mm (5 mm thickness)
• Perspex protection cover with hinges 200X200 mm
• Pad locking arrangement
• Gland box attached to the bottom
• Ingress protection: Up to IP65

TRANSPARENT DOOR ENCLOSURE

• Door frame made of EG steel powder coated
• UV resistant, flame retardant polycarbonate transparent door pane
• Transparent door pane suitable for outdoor applications
• Corner formed door ensures better weatherproofing and gives aesthetic looks.
• Gasket on door ensures better sealing.
• Dimensions:From 200×200 mm To 1600×1000 mm
• Depths:From 150 mm To 400 mm
• Ingress protection : IP65

SWITCH BOXES

• Material: Hot-dipped galvanized steel
• Steel thickness: 0.9 or 1.1 mm
• Dimensions: 72 × 72 mm, 72 × 132 mm
• Depths: 35 mm, 47 mm
• Knockouts: 26.5 mm, 20.5 mm

OPTIONS

• With adjustable lug
• With brass earth terminal
• With steel earth terminal
• With couplers: 2, 3 & 4

JUNCTION BOXES

• Material: Hot-dipped galvanized steel
• Steel thickness: 0.9 mm
• Dimensions: From 100 × 100 mm to 450 × 450 mm
• Depths: 55 mm, 75 mm, 100 mm
• Knockouts: 26.5 /32.5 mm, 20.5/26.5 mm

OPTIONS

• Surface & flush applications
• With rectangular knockouts
• Available with 1.1 mm steel thickness and brass earth terminal

ELECTRICAL SWITCHES & SOCKET

Alfanar electric offers high-quality electrical switches, sockets, dimmers, and other wiring accessories in arange of designs and colors. Our wiring accessories are easy to install and they are built to last whether they’re being used in home, office or leisure environments.

PRODUCT RANGE

Switch series – Alf, Mira, Omnia, Sidra, Granada & Masa

• Alf – The alf range is lab-tested, Quality Mark certified, and includes a warranty, support, and cover plates.
• Mira – The Mira range is durable, modern, lab-tested, and comes with a Quality Mark, warranty, and support.
• Omnia – Omnia offers a full, durable metal-framed wiring-accessory range, lab-tested and Quality Mark certified, with a warranty, support, and many styles and colors.
• Sidra – Sidra wiring accessories feature a contemporary design, are lab-tested and Quality Mark certified, include a replacement warranty and support, and come in two colors.
• Granada – Granada wiring products feature a modern look with a durable metallic frame, are Quality Mark certified, include cover plates, and come with a replacement warranty and full support.
• Masa – Masa offers a full range of curved, slim wiring accessories with a new design for faster, more stable installation. They are made from durable, flexible, flame-retardant thermoplastic for long-lasting performance.

Alfanar Weatherproof Range – IP66 Weatherproof products use a robust thermoplastic enclosure for indoor or outdoor areas needing water and dust protection. Their IP66 rating ensures a sealed design that blocks water and dust ingress.
